Feature:

• 100 times/sec. High speed sampling
• High display resolution to 16,000 counts
• Up to 1 million counts of A/D resolution
• Monitor & control weighing and batching with external or internal resolution
• Fuzzy and Automatic Free Fall Compensation (AFFC) for consistently accurate batching results
• Enter control set points through front keys or remotely through external thumb wheels
• Automatics weight and/or count accumulation
• Sub display provides feedback on all setpoints & simplifies calibration
• Supplementary flow function assures accurate performance on each batch
• A host of communications capabilities:
  RS-232C, RS-422/485, BCD, analog output and standard 4-20mA current loop
• Connect up to 10 AD-4401’s with A&D’s RS-422/485
• Compact DIN size housing speeds installations & reduces space
• Digital Span Calibration enhances technical support & difficult installations
• Splash proof front panel and keys (IP-65)
• High sensitivity 0.3µV/d for more accurate measurements
• Automatic batching and customer programming capability
• Bright, clear fluorescent displays
• Hold and peak hold functions
• User programmed timer settings and alarms, improve operational safety & performance
• Weigh-in and Loss-in-weigh batching

System self-Diagnostics

The most important factor in the installation of any weighing or controlling system is to assure that all cables, I/O connections and options are set up and working correctly. This can be very time consuming and difficult, adding to the expense of the installation. The AD-4401 solves this problem by providing system Self-Diagnostic that can check.

• All installed option
• All I/O connections (without the need for test equipment)
• Setpoints connections
• Control keys
• A/D converter input value

Superior Free-Fall Control

The type of material being batched, ambient temperature, flow rate, consistency of the material, and many other factors impact the accuracy of any batching process. The AD-4401 provides two types of free fall compensation which may be selected according to batching inconsistent material, such as sand with stones; honey whose flow rate changes according to ambient temperature; and flour, which is susceptible to sticking to the sides of the discharge gate.

High performance A/D converter

New Sigma Delta A/D converter IC provides high speed, high resolution and high sensitivity in a very small package, that saves space, reduces parts and lowers cost.
