TIMBANGAN LANTAI – FLOOR SCALE 3 TON 1.5 M X 1.5 M
MK-Di03 Digital weighing indicator can be used with 1 – 4 SLB-D or digital load cell. It has the function of accumulation and unit switch over and applies to small platform scale, weighbridge and farmers scale.
CHARACTERISTIC AND FUNCTIONS |
|
| Stainless steel enclosure | Clock function: year, month, date, hour, minute, second, auto leap year, leap month |
| Calibration switch code | External parallel printer: allow single weigh, fixed printing format, not support printing record checking |
| Support accumulation, clear, unit switching, by function key checking , printing accumulation data, times…etc | Support regular shutdown, random code decryption function |
| Input password before calibration and adjusting | Auto networking and auto auto-creating weighing scale system |
| Automatic and manual corner-difference adjustment | Power on, auto zero-setting range, manual zero-setting range can be set separately, zero tracing range can be set |
| Random charging by indicator, low power indication and voltage status monitoring | RS232 communication interface, multi communication protocol |
| Encryption function is available while load cell and indicator is communicating | Digital load cell SN checking, overload record checking function |
| Scoreboard interface, series port communication port and standard parallel Printer interface, fixed pound printing format | Equipped with EMC protection |
MAIN TECHNICAL PARAMETERS |
|
| Digital load cell interface | RS485, max transmission distance £ 75m |
| Transmission speed rate | 19200 bps |
| Digital load cell power supply | DC 12V/750mA |
| Digital load cell connection quantity | 1 ~ 4 pcs |
| Digital load cell communication protocol | MK-LUD-P protocol, MK-SLB-D protocol |
| Display | 7 LED digital tube with 1.2 inch red light, 7 state instruction |
| Scoreboard interface | Current loop serial output, RS232, 600 bps, transmission distance £ 100m |
| Serial communication interface | RS232, 600 ~ 19200 bps optional |
| Printer interface | Standart parallel print interface, recommend EPSON LQ/300K + II Panasonic KX-P1121/1131, POS 58 printer |
| Indicator power supply | AC : Switch power supply 100V ~ 200V/AC, 50Hz Optional DC : External connection batteries, 12V/DC |
| Operating temperature | 0°C ~ 40°C Humidity : £ 85% (RH) |
| Storage temperature | -10°C ~ 60°C Storage Humidity : £ 95% (RH) |
| Dimension | 293 x 210 x 70mm |
SPECIFICATIONS |
||
| Platform Size | Capacity | Readability |
| 1000 x 1000mm | 500kg | 0.2kg |
| 1000 x 1000mm | 1000kg | 0.5kg |
| 1200 x 1200mm | 500kg | 0.2kg |
| 1200 x 1200mm | 1000kg | 0.5kg |
| 1200 x 1200mm | 2000kg | 1kg |
| 1200 x 1500mm | 2000kg | 1kg |
| 1200 x 1500mm | 3000kg | 1kg |
| 1500 x 1500mm | 1000kg | 0.5kg |
| 1500 x 1500mm | 2000kg | 1kg |
| 1500 x 1500mm | 3000kg | 1kg |
| 1500 x 1500mm | 5000kg | 2kg |
| 1500 x 2000mm | 1000kg | 0.5kg |
| 1500 x 2000mm | 2000kg | 1kg |
| 1500 x 2000mm | 3000kg | 1kg |
| 1500 x 2000mm | 5000kg | 2kg |
| 2000 x 2000mm | 1000kg | 0.5kg |
| 2000 x 2000mm | 2000kg | 1kg |
| 2000 x 2000mm | 3000kg | 1kg |
| 2000 x 2000mm | 5000kg | 2kg |
| 2000 x 3000mm | 2000kg | 1kg |
| 2000 x 3000mm | 3000kg | 1kg |
| 2000 x 3000mm | 5000kg | 2kg |
Brand : MKcells Kategori : Timbangan Lantai (Floor Scale)
