INDIKATOR TIMBANGAN CI – 1580 A MERK CAS
FEATURES
- High-visibility LED display
- Shielded against noise (RFI, EMI)
- High-speed A/D conversion (200 times/sec) & high display resolution (1/10,000)
- Watch-dog & self-hardware test function
- Weight back-up function
- 2 external relay inputs & 3 external relay outputs
- Terminal block installed
- By using DC power, input power can be used in 12~24VDC regardless of polarity (300mA or over is advisable)
- Simple and prompt Full Digital Calibration
- Equivalent input mode for Calibration
- Variety of applications ( Platform scale, Truck scale, checking scale, packing scale, tester etc)
- Option :
> 12 or24 VDC adapter
> RS-422/485
> Analog out(V-out: 0~10V, I-out: 4~20mA)
SPECIFICATIONS
| Model Name | CI-1580A | |
| Load Cell applied voltage | DC 10V (±5V) | |
| Zero-point Calibration Range | – 0.6mV ∼ + 1.5mV | |
| Input Sensitivity | 0.3㎶ / D | |
| Internal Degradability | 520,000 Count(19bit) | |
| Max/ Signal Input Voltage | 32mV | |
| Indication Unit | 5-digit red high intensity LED (Font size : 12.7(H)x7.3(W)mm | |
| Below Zero-point indication “-” | ||
| A/ D Conversion Speed | 200 times / second | |
| Temperature used | -5℃ ~ +40℃ | |
| Product Dimension | 100(W) X 125(D) X 52(H) | |
| Product Weight | Approximately 0.45 | |
| Interface | Standard | RS-232C |
| Option | RS-422/485, Analog out(I/V-out) | |
