LOAD CELL MK SLB – SS – MK CELLS
| Specifications | |||
| Rated Capacities (Emax) | 0.25, 0.3, 0.5, 0.75, 1, 1.5, 2, 2.5, 3, 5, 7.5, 10t | Temperature, Compensated | -10°C ~ +40°C |
| Rated Output | 3.0 ± 0.003mV/V (0.5-10t), 2.0 ± 0.002mV/V (0.25-0.3t) | Temperature, Operating | -30°C ~ +70°C |
| Accuracy Class | C5 | Maximum Safe Overload | 150% FS |
| Zero Balance | ± 1% FS | Ultimate Overload | 180% FS |
| TC Zero | ± 0.02% FS/10°C | Excitation, Recommended | 10 ~ 12V DC |
| TC Span | ± 0.02% FS/10°C | Excitation, Maximum | 15V DC |
| Input Resistance | 400 ± 20Ω | Protection Class | IP67 (0.2-0.75t), IP68 (1-10t) |
| Output Resistance | 352 ± 3Ω | Contruction | Stainless steel |
| Insulation Resistance | ≥ 5000MΩ | Cable | Length : 3m (0.25-2.5t), 4.2m (3-5t), 5m (7.5-10t) |
| Diameter : Φ 5mm (0.25-5t, 0.25-0.3t), Φ 6mm (7.5-10t, 0.5-10t) | |||
| Features | |
| High quality shear beam load cell | Stainless steel with anti corrosive |
| Standart leveling foot for universal application | Can use for silo, hopper, low platform scale |
| 5 core high quality orange cable | |
