TIMBANGAN LANTAI / FLOOR SCALE SURABAYA
MK-Di02 Digital weighing indicator can be used with 1 – 4 SLB-D or digital load cell. It has the function of accumulation and unit switch over and applies to small platform scale, weighbridge and farmers scale.
CHARACTERISTIC AND FUNCTIONS |
|
| Plastic housing | Calibration switch code |
| Support regular shutdown, random code decryption function | Input password before calibration and adjusting |
| Auto networking and auto auto-creating weighing scale system | Automatic and manual corner-difference adjustment |
| Power on, auto zero-setting range, manual zero-setting range can be set separately, zero tracing range can be set | Random charging by indicator |
| RS232 communication interface, multi communication protocol | Encryption function is available while load cell and indicator is communicating |
| Digital load cell SN checking, overload record checking function | Equipped with EMC protection |
MAIN TECHNICAL PARAMETERS |
|
| Digital load cell interface | RS485, max transmission distance ≤ 75m |
| Transmission speed rate | 19200 bps |
| Digital load cell power supply | DC 12V/750mA |
| Digital load cell connection quantity | 1 ~ 4 pcs |
| Digital load cell communication protocol | MK-SLB-D protocol |
| Display | 6 LED digital tube with 1.2 inch red light, 7 state instruction |
| Serial communication interface | RS232, 600 ~ 19200 bps optional |
| Indicator power supply | AC : Switch power supply 110V ~ 200V/AC, 50Hz |
| Operating temperature | 0°C ~ 40°C Humidity : £ 85% (RH) |
| Storage temperature | -10°C ~ 60°C Storage Humidity : £ 95% (RH) |
SPECIFICATIONS |
||
| Platform Size | Capacity | Readability |
| 1000 x 1000mm | 500kg | 0.2kg |
| 1000 x 1000mm | 1000kg | 0.5kg |
| 1200 x 1200mm | 500kg | 0.2kg |
| 1200 x 1200mm | 1000kg | 0.5kg |
| 1200 x 1200mm | 2000kg | 1kg |
| 1200 x 1500mm | 2000kg | 1kg |
| 1200 x 1500mm | 3000kg | 1kg |
| 1500 x 1500mm | 1000kg | 0.5kg |
| 1500 x 1500mm | 2000kg | 1kg |
| 1500 x 1500mm | 3000kg | 1kg |
| 1500 x 1500mm | 5000kg | 2kg |
| 1500 x 2000mm | 1000kg | 0.5kg |
| 1500 x 2000mm | 2000kg | 1kg |
| 1500 x 2000mm | 3000kg | 1kg |
| 1500 x 2000mm | 5000kg | 2kg |
| 2000 x 2000mm | 1000kg | 0.5kg |
| 2000 x 2000mm | 2000kg | 1kg |
| 2000 x 2000mm | 3000kg | 1kg |
| 2000 x 2000mm | 5000kg | 2kg |
| 2000 x 3000mm | 2000kg | 1kg |
| 2000 x 3000mm | 3000kg | 1kg |
| 2000 x 3000mm | 5000kg | 2kg |
Brand : MKcells Kategori : Timbangan Lantai (Floor Scale)
